48V 50A Skylla TG Dual-Chemistry Battery Charger — Supports SLA & LiFePO4, 50A Output, M8 Terminal Connections

Description

48V 50A Skylla TG SLA Single Output 50A Charger with M8 Connection SDTG4800501

Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system. In particular, sealed maintenance free batteries must be charged correctly in order to ensure a long service life. Overvoltage will result in excessive gassing and venting of a sealed battery. The battery will dry out and fail. Except for the 3-phase input models, the chargers also accept a DC supply. Every TG Charger has a microprocessor, which accurately controls the charging in three steps. The charging process takes place in accordance with the IUoUo characteristic and charges more rapidly than other processes. As a result of the perfectly stabilised output voltage, a TG Charger can be used as a power supply if batteries or large buffer capacitors are not available. The TG Chargers feature 2 isolated outputs. The second output, limited to approximately 4A and with a slightly lower output voltage, is intended to top up a starter battery. In order to compensate for voltage loss due to cable resistance, TG Chargers are provided with a voltage sense facility so that the battery always receives the correct charge voltage.

Features:

• Skylla TG SLA Single Output 50A Charger with M8 Connection
• Except for the 3-phase input models, the chargers also accept a DC supply
• The charging process takes place in accordance with the IUoUo characteristic

Every Skylla TG Charger comes with a battery temperature sensor. When connected, charge voltage will automatically decrease with increasing battery temperature. This feature is especially recommended for sealed batteries which otherwise might be overcharged and dry out due to venting.
